The worldwide drive to improved energy efficiency for engine systems is being supported by several engine R&D programs at Southwest Research Institute (SwRI). This research includes large programs in major-market engine categories, such as heavy-duty, non-road, and light-duty; and includes diesel, gasoline, and alternative fuel aspects. This presentation describes several key diesel engine programs being pursued under the SwRI Clean High Efficiency Diesel Engine consortium (CHEDE-VI), whose goal is to demonstrate future diesel technology exceeding 50% brake thermal efficiency. Additionally, SwRI?s High Efficiency Dilute Gasoline Engines consortium (HEDGE-II), is reviewed, where advanced technology for ultra-high efficiency gasoline engines is being demonstrated. The HEDGE-II program is built upon dilute gasoline engine research, where brake thermal efficiencies in excess of 42% are being obtained for engines applicable to the light-duty market. Presenter Charles E.

The copper-rotor induction-motor made its debut in automotive electric traction in 1990 in GM's Impact EV. Since then, this motor architecture has covered millions of miles on other vehicle platforms which will soon include Toyota's RAV4-EV. With the industry's attention focused on cost-effective alternatives to permanent-magnet traction motors, the induction motor has returned to the spotlight. This talk will overview where the copper-rotor induction-motor is today, how the technology has evolved since the days of the GM Impact, the state-of-play in its mass-manufacturing processes and today's major supply-chain players. Presenter Malcolm Burwell, International Copper Association Inc.

The traction motor is key to the �synergy of the electric powertrain�, the overall functionality of the battery, e-motor, power control electronics, and charging system. Therefore some automakers have decided to design, develop, and produce their traction motors in house while some others are working with suppliers for their electric power train motors. Off-the-shelf motors, no matter how extensively they are adapted for a specific application, can compromise the efficiencies of the propulsion system. Presenter Marc Winterhoff, Roland Berger Strategy Consultants

With automotive electrification, the electric machines show a tendency to share or even replace the dominant role of internal combustion engines in future vehicles. Besides the design and innovation of different electric machines to meet the needs of powertrain and drivetrain performances, high volume production becomes a challenging topic and an un-avoided requirement. Flexible line and sharing line will help the variation of production rate and volume, while the dedicated unique line contributes to large scale of E-motor production. Supplier chain from raw materials, parts to processes has to be built from ground-zero or low grade to mature stage within quality specification and time limitation. Multi function skills, cross area technologies and complex management etc are all required for E-motor manufacturer to grow up with component and equipment suppliers. Reducing cost, improving quality and guaranteeing safety are always the thematic series.

There has recently been a great deal of hypothesizing and prognosticating about the security of supply of the rare earths for the non-Chinese OEM automotive industry. The pundits and industry analysts have warned of demand destruction by substitution driven by sustained high prices as well as due to supply interruptions. What has been overlooked for the most part is that the issue is not about all of the rare earths; it is just about some of them, the critical rare earths. And even in that category there are two separate issues: 1) Is there enough production of the light rare earth, neodymium, to sustain current demand and can its non-Chinese production grow to meet expected non-Chinese demand? and 2.) Is there even enough production of the heavy rare earths, dysprosium and terbium, to meet current Chinese demand and is it possible to produce dysprosium a.) Outside of China, and b.)

Those who are concerned about access to rare earths and other critical minerals for EV powertrains are focused on the exact wrong problem. Mr. Thomas discusses why it's control of process technology, not the raw ores themselves, that dictates cost, availability and performance. Presenter Lawrence B. Thomas, Primet Precision Materials

As the need to develop better and less expensive batteries for automotive applications continues, we will likely need to examine potential tradeoffs between enhanced performance and costs. In particular, the choice of cathode materials automatically involves changes in performance and material costs. We will examine some of the possible cathode materials for use in next-generation battery packs, and the financial implications regarding those materials. Presenter Jon Hykawy, Byron Captial Markets

For internal combustion engines and industrial machinery, it is well recognized that the most cost-effective way of reducing energy consumption and extending service life is through lubricant development. This presentation summarizes our recent R&D achievements on developing a new class of candidate lubricants or oil additives ionic liquids (ILs). Features of ILs making them attractive for lubrication include high thermal stability, low vapor pressure, non-flammability, and intrinsic high polarity. When used as neat lubricants, selected ILs demonstrated lower friction under elastohydrodynamic lubrication and less wear at boundary lubrication benchmarked against fully-formulated engine oils in our bench tests. More encouragingly, a group of non-corrosive, oil-miscible ILs has recently been developed and demonstrated multiple additive functionalities including anti-wear and friction modifier when blended into hydrocarbon base oils.

This presentation will cover an overview of challenges and key discussion points for advanced electric motor and drive testing . Voiko will visit some examples of how D&V approaches these issues and also some suggestions for how the industry can view these intriguing problems as opportunities. The presentation will also delve into current testing developments that involve resolver, load bank and power measurement devices by highlighting solutions in the market today. There will also be a cursory look into the future of electric motor testing and what we can expect in the near term. Presenter Voiko Loukanov, D&V Electronics Limited

The benefits of adding variable compression ratio (VCR) capability to a Gasoline Turbocharged Direct Injection (GTDI) has been experimentally explored by AVL to quantify the potential efficiency improvements along with other combustion benefits and challenges. The development process is discussed along with key results showing how the combination of VCR, GDI, external cooled EGR and variable cam phasing was optimized to achieve maximum benefit. The concept demonstrates aggressive downsizing capability with BMEP levels above 40 bar BMEP with a two-stage turbocharging system on 95 RON gasoline. The iso-BSFC sweet spot was also improved with reduced BSFC over a broader operating range. The issues of knock, low speed pre-ignition, particulates and sensitivity to octane level and ambient temperature conditions were also investigated and are discussed. Engine level results are shown translated into predicted NEDU vehicle fuel economy improvements.

This presentation focuses on the efforts Coordinating Research Council is sponsoring relating fuel properties and composition to performance in emerging advanced high efficiency, clean combustion engines. Presenter William J. Cannella, Chevron USA Inc.

Downsizing and downspeeding are two efficient strategies to reduce vehicles CO2 emission, provided that high BMEP can be achieved at any engine speed under clean, safe, stable and efficient combustion. With a 6:1 minimum compression ratio, the MCE-5 VCRi achieves 40 bar peak BMEP at 1200 rpm with no irregular combustion. If peak BMEP is maintained below 35 bar, fuel enrichment is no longer necessary. When running at part loads, the engine operates at high compression ratios (up to 15:1) to minimize BSFC and maximize the sweet spot area on the map. Next generation MCE-5 VCRi engines will combine VCR and stoichiometric charges, highly diluted with external cooled EGR, in order to improve part loads efficiency by means of both the reduction in heat and pumping losses, and the optimization of compression-expansion ratio. This strategy, added to downsizing-donwspeeding, requires high-energy ignition systems to promote repeatable, stable, rapid and complete combustion.

Historically, the opposed-piston, two-stroke (OP2S) diesel engine set combined records for fuel efficiency and power density that have yet to be met by any other engine type. However, with modern emissions standards, wide-spread development of this engine for on-highway use stopped. At Achates Power, state-of-the-art analytical tools and engineering methods have produced an OP2S engine that, when compared to a leading medium-duty engine, has demonstrated a 21% fuel efficiency gain and engine-out emissions levels meeting U.S. EPA10 with conventional after-treatment. Among the presentation topics covered are thermodynamic efficiency, demonstrated engine results, cost and weight advantages, and overcoming two-stroke engine challenges. Presenter David Johnson, Achates Power Inc.

Ford's EcoBoost GTDI engine technology (Gasoline Direct Injection, Turbo-charging and Downsizing) is being successfully implemented in the market place with the EcoBoost option accounting for significant volumes in vehicle lines as diverse as the F150 pickup truck, Edge CUV and the Lincoln MKS luxury sedan. A logical question would be what comes after GTDI? This presentation will review some of the technologies that will be required for further improvements in CO2, efficiency and performance building on the EcoBoost foundation as well as some of the challenges inherent in the new technologies and approaches. Presenter Eric W. Curtis, Ford Motor Co.

Combustion engines are typically only 20-30% efficient at part-load operating conditions, resulting in poor fuel economy on average. To address this, LiquidPiston has developed an improved thermodynamics cycle, called the High-Efficiency Hybrid Cycle (HEHC), which optimizes each process (stroke) of the engine operation, with the aim of maximizing fuel efficiency. The cycle consists of: 1) a high compression ratio; 2) constant-volume combustion, and 3) over-expansion. At a modest compression ratio of 18:1, this cycle offers an ideal thermodynamic efficiency of 74%. To embody the HEHC cycle, LiquidPiston has developed two very different rotary engine architectures ? called the ?M? and ?X? engines. These rotary engine architectures offer flexibility in executing the thermodynamics cycle, and also result in a very compact package. In this talk, I will present recent results in the development of the LiquidPiston engines. The company is currently testing 20 and 40 HP versions of the ?M?

In this presentation, we will explain how the traditional Miller Cycle - which has its limitations in the traditional four-stroke, Otto Cycle engine provides new opportunities for greater fuel efficiency gains and engine downsizing when incorporated in a split-cycle combustion process. Results will also be shared from studies showing how these implementations can provide both significant drops in fuel consumption and increases in power when incorporated into some of today's most economic vehicles. Presenter Stephen Scuderi, Scuderi Group LLC

Gasoline engines continue to suffer from significant pumping losses despite decades of effort focused on reducing throttling. Honeywell Turbo has developed a throttle with an integrated turbine/generator that generates electricity by recovering pumping work. This energy offsets power normally provided by the crank driven alternator, thereby saving fuel. It integrates well with modern electrical systems which employ smart charging and idle stop strategies. The ThrottleCharger provides fuel economy benefits up to 5% over federal test cycles and in real world conditions. Presenter Mike Guidry, Honeywell Int'l (Turbo Technologies)

Future fuel economy targets represent a significant challenge to the automotive industry. While a range of technologies are in research and development to address this challenge, they all bring additional cost and complexity to future products. The most cost effective solutions are likely to be combinations of technologies that in isolation might have limited advantages but in a systems approach can offer complementary benefits. This presentation describes work carried out at Ricardo to explore Intelligent Electrification and the use of Stratified Charge Lean Combustion in a spark ignition engine. This includes a next generation Spray Guided Direct Injection SI engine combustion system operating robustly with highly stratified dilute mixtures and capable of close to 40% thermal efficiency with very low engine-out NOx emissions.

Turbulent Jet Ignition is an advanced spark initiated pre-chamber combustion system for otherwise standard spark ignition engines. Combustion in the main chamber is initiated by jets of partially combusted (reacting) pre-chamber products which provide a high energy ignition source. The resultant widely distributed ignition sites allow relatively small flame travel distances enabling short combustion durations and high burn rates. This presentation outlines development of this combustion concept in a modern normally aspirated PFI production engine. Experimental results have highlighted high thermal efficiency (42.8%), significant fuel economy improvement (>20%), low engine out NOx (<10 ppm), knock limit extension, high load capability (>13 bar IMEPn) and high speed operation (5500 rev/min). Presenter William P Attard, MAHLE Powertrain LLC

The SAE 2012 World Congress theme, Get Connected, represents the new and diverse connections that will drive significant advancements in the auto industry of tomorrow. Not only does the theme symbolize literal connections, such as those between vehicles, infrastructure, the Internet, and the nation's electrical grid, but also demonstrates the most fundamental of connections; the connections and relationships between engineers who are developing the next generation vehicle technology. From OEMs to suppliers, across academia and governments, connecting to one another and using these connections to share ideas and expertise - in both healthy competition and in partnership - will be the catalyst of forthcoming innovation and the auto industry's basis to continued future success. GetConnected: SAE 2012 World Congress April 24-26, 2012 Cobo Center, Detroit, Michigan, USA Start connecting today. Vist www.sae.org/congress for more information.
